Details
1.Classical double reverb effect, can sing more comfortable with this device.
2.LCD screen. Easy to set the data.
3.Single reverb and stereo can switch , it`s suitable for everyone.
4.Professional feedback suppressor module inside.
5.5.1 balanced outputs, can be flexible with power amplifier.
6.With center and surround outputs channel, volume can be adjusted independent.
7.SUB channel is with 45—250Hz frequency to set. And with auto decay, decay rate can be adjusted.
8.MIC and music are with 3 bands EQ. Analog effect is with 3 bands EQ.
9.Initial & MAX Volume of music. MIC and effect can be set.
Technical Parameter | ||||||||||
Items | Parameter | Test | ||||||||
Output channel | main output(L/R) | √ | ||||||||
center | √ | |||||||||
Subwoofer | √ | |||||||||
Surround(L/R) | √ | |||||||||
S/N | MIC | 75dB | 1KHz OdB input | |||||||
MUSIC | 90dB | |||||||||
THD | MIC | 0.03% | 1KHz OdB | |||||||
MUSIC | 0.01% | Output | ||||||||
MAX Input Level | MIC | 300mv | 1KHz | |||||||
MUSIC | 6V | input | ||||||||
MAX output Level | MIC | 10Vrms | 1KHz | |||||||
MUSIC | 10Vrms | Output | ||||||||
Sensitivity | MIC | 15mV | ||||||||
MUSIC | 300mv | |||||||||
Input impedance | MIC | 10K unbalance | ||||||||
MUSIC | 47K unbalance | |||||||||
Channel seperation | 85dB | |||||||||
Output impedance | 300 balance,1K unbalance | |||||||||
Feed back inhibition | √ | |||||||||
Input parameter | MIC | BASS:100Hz(±15dB),MID:1KHz(±15dB), TREBLE:10KHz(±15dB) |
||||||||
MUSIC | BASS:100Hz(±15dB),MID:1KHz(±15dB), TREBLE:10KHz(±15dB) |
|||||||||
Weight | NetmWeight | 3.0KG | ||||||||
Gross Weight | 3.5KG | |||||||||
Dimensions(W*H*D) | Unit Dimensions | 485*181*45mm | ||||||||
Package Dimensions | 555*256*85mm |
Additional Information
Manufacturer | GDHD |
---|---|
Color | Black |
