細節
FEATURES
- Remote access via computer through USB connection.
- Stereo headphone connection to allow monitoring effects.
- 3.55 mm audio input for your favorite mobile devices such as smart phones and tablets.
- DSP (Digital Signal Processing) technology customized by Better Music Builder .
- 5-D PRO Audio 900 Watts Max Power.
- 3/5 + 1 (subwoofer) audio distributions.
- Full reverberation effects with Microphone reverb, echo, delay, and repeat adjustments.
- Dedicated 3 channels Power Output plus full array of Line Outputs which includes: record output, line output, pre-output, bass output, center channel output.
- Dedicated wireless microphone connection input in 2 groups. The volume of each group can be adjusted separately, with each group provides +/- 8dB adjustment for treble, median, and bass.
- Independent Master and Microphone maximum volume locking.
- Built-in Subwoofer and Center output stereo crossover with independently adjusted volume and cut-off frequency control from 20 Hz ~ 240 Hz.
- High-performance 24-bit dual-engine Feedback Destroyer.
- Full computerized Smart Auto Input Switching (SAIS) feature for source input selection.
- Music modulation with 9-step key control and preset effects for selection.
- Independently adjusted center speaker control for self vocal monitoring.
- Capable of driving two pairs of main speaker in different size to cover the whole frequency spectrum.
- Three extra AC power outlets for additional equipment, programmable in both 110V and 220V
- Music “Mute” allows the microphone to be active while the music is off.
TECH SPECS
- Source Input: KOD (Manual), DVD(BGM), VOD (Main)
- Input Function: SAIS (Auto & Manually)
- Power Output: 900 Watts (8 Ohm) 5-Channel Output
- Microphone Input: 5 (Front x 3, Rear x 2)
- Video Inputs: 3 (RCA jacks)
- Video Outputs: 1 (RCA jacks)
- Audio Inputs: 3 (RCA jacks)
- Audio Outputs: 3 (RCA jacks)
- Music Input Section
- THD: <0.03%
- Input Sensitivity/Impedance: 200mV/10k Ohm
- HF (increase/attenuate): ±8 dB
- LF (increase/attenuate): ±8 dB
- Key Control: 9 steps
- Mic. Input Section
- Input Sensitivity/Impedance: 20mV~40mV/2k Ohm
- Equalize
- Low: 100Hz ± 8 dB
- Middle: 1kHz ± 8 dB
- High: 10kHz ± 8 dB
- Standard Power: AC 120V/~60Hz (North America Market) / AC 220V/~50Hz (Asia or Europe Market)
- Frequency Response: 20Hz~20kHz, ± 1 dB
- Power Consume: 30 Watts
- Dimensions (WxHxD): 17×5.7×15.1 in / 43×14.5×38.4 cm
- Packing Dimensions (WxHxD): 20.4×8.7×17 in / 51.8×22.1×43.2 cm
- Net Weight: 37.9 Lbs / 17.2 Kg
- Shipping Weight: 43.4 Lbs / 19.7 Kg
- UPC Code: 743062980421
其他資訊
| 生產廠家 | Better Music Builder |
|---|---|
| 顏色 | 黑色 |
