細節
型號Model: Mate422
8Ω:4 x 2200W
4Ω:4 x 3300W
2Ω:4 x 3740W
其他資料Other Specification
頻響Frequency response:20Hz-20KHz,-0.5dB(+/-0.5dB)
總諧波失真THD+N:<0.1%
信噪比S/N rate:110dB
阻尼係數Damping factor:>500
分離度Crosstalk:≥70dB
轉換速率Slew rate:>20V/μs
輸入靈敏度Input sensitivity:0.775V/1.0V
輸入阻抗Input impedance (bal/unbal):20kΩ/10kΩ
輸出類別Output circuitry:Class D
冷卻CoolingAir flow from front to rear
連接Connector
輸入Input:XLR 3pin-XLR/RCA/TRS
輸出Output:SpeakON Nl 4輸出插座touch-proof binding posts
功能Function
前面板指示Front pane indictorlPower / SIG / clip / Protect indicator
前面板Front panelPower switch / Volume control
後面板Rear panelOperation mode / Input sensitivity
尺寸和重量Dimension/weight
產品尺寸Product dimension(mm) 483x350x88
產品包裝尺寸Packing dimension(mm)565x550x145
毛重G.W.:14kg
供電要求Power:AC90V-220V/50Hz,±10%
備註:
1、此功率是按照EIA標準測量得出.
2、此功率是使用40ms脈衝1kHz正弦波在1%總諧波失真下測量得出。
Remarks:
1. This power is measured according to the EIA standard.
2. This power is measured using a 40 ms pulsed 1 kHz sine wave at1% total harmonic distortion.
其他資訊
生產廠家 | 花都影音 |
---|---|
顏色 | 黑色 |
